Front panel

Iron, black

Power supply

AC90-260V 50-60HZ (Single phase 3-core, positive, negative, ground), equipped one 32A waterproof VDE type plug(Single phase 3-core)

Power output channels

6 groups 3 groups of16A universal sockets 3 groups 16A VDE sockets

Full range signal input channels

4 groups

Full range signal output channels

4 groups

Speaker loading input channels

16 groups

Output channels

16 groups

Controlled output

5000W/10000 Maximum single channel withstanding reactive power /total power

Output power sockets

Flame retardant ABS & phosphorous copper material, capable of withstanding current up to 16A; 3 standard universal sockets & 3 VDE sockets

Protection

An independent air circuit-breaker is available at each channel. The air circuit-breaker automatically powers off to protect the audio equipment from damage if short circuit or overcurrent occurs.

Control

Manually control for each channel ON/OFF, 1-2 channels with one switch, 3-4 channels with one switch, and 5-6 channels with one switch

Power supply

AC90-260V 50-60HZ

Power connector

Waterproof 32A VDE type plug connect to 3-cord cables

ON/OFF

Air circuit-breaker

Product dimensions

482×315×88mm (WxDxH)

shippingdimensions

530×530×160mm (WxDxH)

N.W/G.W

6.6kg/8.8kg
