Front panel

Iron, black

Power supply

AC90-260V 50-60HZ (Single phase 3-core, positive, negative, ground,Single phase 3-core)

Power output channels

5 groups

Full range signal input channels

4 groups

Full range signal output channels

4 groups

Speaker loading input channels

8 groups

Output channels

8 groups

Controlled output

5000W/10000W Max withstanding reactive power

Output power sockets

Flame retardant ABS & phosphorous copper material, capable of withstanding current up to 16A

Protection

An independent air circuit-breaker is available at each channel. The air circuit-breaker automatically powers off to protect the audio equipment from damage if short circuit or overcurrent occurs.

Power supply

AC90-260V 50-60HZ

Product dimensions

482×185×44mm (WxDxH)

shippingdimensions

555×255×85mm (WxDxH)

N.W/G.W

3.7kg/4.1kg
